8HPTHEWORLD / SUPRA MKIV

Your Supra.
Eight speeds.
One clear plan.

Build your 2JZ to Dodge 8HP70 swap around the parts you need, the parts you own, and the way you drive.

JZA80 / 2JZDodge 8HP70Built with Perfect Tuning

YOUR MECHANICAL FOUNDATIONSupra MKIV Base Swap KitCharger / Challenger / 300C RWD donor · Ram variants require different parts

Part selections are saved on this browser for 30 days. Prices refresh when you reload.

01 / THE STARTING POINT

Tell us about your Supra.

A few details help us identify the right mechanical and electrical requirements.

Engine VVT-i Current engine ECU Primary use Turbo setup Factory engine oil cooler

Add details for the wiring review

Model yearSteering positionECU model / part numberTarget power

Supra first. More platforms to follow.

02 / COMPLETE THE INSTALLATION

Make the parts work together.

Supra MKIV mechanical kit — donor to confirm

Identify your 8HP70 donor to confirm the adapter kit, driveshaft and transmission mount.

I already own this kit

Transmission

Where is your transmission coming from? Transmission preparation

Why the 8HP70 donor matters

Dodge 8HP70 — Charger / Challenger / 300C RWD: our Supra kit bolts on to this transmission.

Ram 1500 5.7 pickup 8HP70: the adapter kit bolts on, but the driveshaft and transmission mount are different. We quote those parts for your installation.

Ram EcoDiesel 8HP70: the swap is still possible, but it needs a completely different adapter kit. We review and quote the correct kit.

Share the donor vehicle, year and transmission identification in your build notes if you are unsure which version you have.

Engine & transmission control

Choose your control strategy

Compare the control options

Choose whether to replace your engine ECU or keep it. Every option still needs the right wiring and transmission preparation.

RECOMMENDED FOR MOST BUILDS

Track Gen2

Engine + 8HP control in one ECU. Our usual recommendation for a complete 2JZ swap.

Patch or complete engine harness required. MaxxECU flash required.

ALTERNATIVE

Race Gen1

Combined engine and transmission control with the previous Race generation.

Patch or complete engine harness required. MaxxECU flash required.

FLAGSHIP

Race Gen2

For demanding builds needing more capability. Usually beyond what a typical 2JZ swap requires.

ECU-only package. Wiring and required accessories are selected separately.

KEEP YOUR ENGINE ECU

Mini 8HP kit

Keep your engine ECU and use the Mini kit for the transmission, subject to compatibility review.

Universal 8HP harness and basic map included. MaxxECU flash required.

ALTERNATIVE WITH YOUR ECU

TurboLamik

Retain your engine ECU with a dedicated transmission controller.

Universal harness and bypass board included. Professional valve-body installation is extra.

Wiring approachShifter style

Flexplate & converter

FlexplateTorque converter

I already have the correct automatic flexplate bolts and spacer

Already have a compatible OEM flexplate? You can keep it. For a new flexplate, choose SFI or DomiWorks 81010001; OEM supply is not offered. Confirm the correct bolts, spacer and converter fitment.

Transmission cooling

Cooling plan

The regular option uses a Vibrant 12952 cooler without a fan. Fan-assisted options depend on mounting space and availability. Lines, fittings and mounting are quoted separately; fan-assisted cooling is recommended for Circle D converters or drift.

03 / FROM INSTALLATION TO FIRST START

Start with specialist support.

RECOMMENDED ADD-ONSwap Startup PackageCAD $650 Base calibration + 2 hours totalA 2JZ starting calibration, a remote startup session and log review, within your included time.

All specialist time counts

In the standard Startup Package, file preparation, calls, logs and technical exchanges share the 2-hour allowance.

Continue when you need to

Additional time: CAD $150/hour, prepaid and tracked in 15-minute increments.

Come prepared

We review your ECU, injectors, fuel, sensors and installation details before the session.

Build on a starting calibration

Full-load tuning and further optimization are separate work. Installation issues must be resolved before tuning continues.

Your build at a glance

Your swap checklist

You can request a quote even if some details are undecided. We will help resolve the items below.

Anything else about your build?

Send your build for a quote

Share your contact details and send this configuration to Perfect Tuning. We will review compatibility, confirm the remaining prices and prepare your quote.

Priced items—Partial estimate · more to quote
